AD480.4 4-Channel Amplifier
AD480.4 4-Channel Amplifier
Sale price$249
AD480.4 4-Channel Amplifier
Overview
Power up your audio system with the AD480.4, a robust 480W 4-channel Class D Amplifier engineered for superior sound and durability. Designed with multi-environment protection and an IPX4 rating, this amplifier is built to withstand tough conditions while delivering consistent, high-quality audio.
Specifications
Specifications
| Type: | Class D Digital Amplifier |
| Environment Protection: | IPX4 Rating |
| Power Output (Max): | 4x 80W |
| RMS @ 2 Ohm (≤1% THD): | 4x 130W |
| RMS @ 4 Ohm (Bridged): | 4x 80W |
| Frequency Response: | 20Hz - 30kHz |
| Signal To Noise Ratio: | 70dB |
| THD: | ≤1% |
| Input Sensitivity: | 2000mV ± 400mV |
| Input Channels: | RCA and speaker level inputs |
| Minimum Load: | 2 Ohm |
| Current Draw: | 51.6A |
| Overload Protection System: | Yes |
| Overheat Protection Temperature: | 75°C |
| Operating Voltage: | 12VDC - 14.4V DC |
