AD600.5 5/4/3-Channel Amplifier
AD600.5 5/4/3-Channel Amplifier
Sale price$369
AD600.5 5/4/3-Channel Amplifier
Overview
Take your marine or powersports audio to the extreme with the AD600.5 amplifier. Boasting 600 Watts of power and advanced digital technology to minimize heat and battery drain, this powerhouse guarantees maximum sound efficiency without sacrificing volume. With Shockwave technology for crystal-clear audio and waterproof protection for all-terrain durability, your music can keep the adventure going strong!
Specifications
Specifications
| Type: | Class D Digital Amplifier |
| Waterproof: | Yes - IP65 |
| Output Modes: | Mono, Stereo, Bridge |
| Input Channels: | 5x RCA |
| Speaker Level Input: | 5 Channels |
| Output Channels: | 5/4/3 |
| Input Impedance: | 22k (RCA), 470 Ohms (Speaker) |
| Output Impedance (Per Channel): | 4 Ohms / 2 Ohms |
| Power Output (Max): | 600W |
| Power Output (Max) @ 4 Ohms, ≤1% THD: | 4x 50W + 1x 200W |
| Power Output (Max) @ 2 Ohms, ≤1% THD: | 4x 75W + 1x 300W |
| Power Output – Bridged @ 4 Ohms, THD ≤1%: | 2x 150W |
| S/N (A-Weighted, 1W @ 4 Ohms): | ≥70dB |
| Frequency Response: | 10-20kHz (1CH To 4CH) 10-250Hz (5CH) |
| Channel Separation: | ≥48dB |
| Input Sensitivity (Low Level): | 200mV To 4V |
| Input Sensitivity (High Level): | 600mV To 10V |
