PSB-1 12V DC Audio Power Supply
PSB-1 12V DC Audio Power Supply
Sale price$129
PSB-1 12V DC Audio Power Supply
Overview
Do you need a new dual input power supply? The PSB-1 110/240V 4-pin Amp/Molex connector is an excellent choice. With a power factor of 0.9 or greater and a power efficiency of at least 87%, this power supply is ready to make sure your tunes never have to stop. Designed to withstand common hazards ranging from water to over voltages and over temperatures, the PSB-1 is a truly durable and reliable piece of equipment.
Specifications
Specifications
| Type: | Regulated Switching Mode Power Supply (≤10A, 13V DC) |
| Water Resistant: | Yes – IPx5 |
| Input Voltage: | 100-240V AC (Power Input Auto Sensing/Switching) |
| Input Frequency: | 50/60 Hz |
| Efficiency: | ≥87% |
| Power Consumption: | ≤0.5W (At 240V AC) |
| Power Factor: | ≥0.9 (At Full Load) |
| Short Circuit Protection: | Continuous |
| Output Plug: | 2x Female Spade Connectors (+13V DC (Red), Neg (Black)) |
| Output Voltage: | 13V DC Regulated |
| Output Current: | 5A |
| Ripple & Noise: | 260mV (Max) |
| Voltage Accuracy: | ±5% |
| Line & Load Regulation: | ±5% |
| Operating Temperature: | -20°C – 70°C |
| Storage Temperature: | -20°C – 85°C |
| Dimensions: | 49 x 234 x 110 mm |
| Certifications: | UL1563 Class2, UL1310, CSA, CE |
| Protection: | Short Circuit, Over Voltage, Over Current, Over Temperature |
